Specifications
- Body Dimensions
- Length2081 mm
- Width756 mm
- Height1103 mm
- Wheel Base1335 mm
- Ground Clearance187 mm
- Kerb Weight139 kg
- Seat Length715 mm
- Seat Height798 mm
- Fuel Tank Capacity13 L
- Engine
- Type4 stroke, SI Engine
- Displacement162.71 cc
- Max Engine Output9.9 Kw @7500 rpm
- Max Torque14.58 N-m @5500 rpm
- Fuel SystemPGM- FI
- Bore X Stroke57.300 X 63.096 mm
- Compression Ratio 10.0:0.1
- Starting MethodKick/Self start
- Transmission
- Clutch TypeMultiplate Wet Clutch
- No. of Gears5
- Tyres & Brakes
- Tyre Size & Type (Front)80/100-18 M/C 47P, Tubeless
- Tyre Size & Type (Rear)100/90-18 M/C 56P, Tubeless
- Brake Type & Size (Front)Disc - 240 mm
- Brake Type & Size (Rear)Drum - 130 mm
- Frame & Suspension
- Frame TypeDiamond Type
- Front SuspensionTelescopic
- Rear SuspensionHydraulic Type (Monoshock)
- Electricals
- Battery12V, 4.0Ah
- Head LampHalogen Bulb
+The technical specifications and design of the vehicles may vary according to the requirements and conditions without any notice. Unicorn meets Bharat Stage VI norms. Product shown in the picture may vary from actual product available in the market. Accessories shown in the picture are not part of standard equipment.
