Specifications

    Body Dimensions

  • Length2095mm
  • Width756mm
  • Height1100mm
  • Wheel base1340mm
  • Ground clearance179mm
  • Kerb weight146kg
  • Fuel tank capacity13L

    Engine

  • TypeAir cooled, 4 stroke, SI engine
  • Cylinder capacity149.1 cc
  • Max net power
  • Max net torque
  • Bore 57.3mm
  • Stroke57.8 mm
  • Compression ratio9.1:1
  • Air filter typeViscous paper filter
  • Starting methodKick/self

    Transmission

  • No of gears5
  • Gear pattern1-N-2-3-4-5
  • Max speed101 Kmph

    Tyres & brakes

  • Tyre size (front)2.75-18
  • Tyre size (Rear)100/90-18
  • Tyre type (front)Tube type
  • Tyre type (rear)Tube type
  • Brake type & size (front)Disc 240mm
  • Brake type & size (rear)Drum 130 mm

    Frame & Suspension

  • Frame typeDiamond
  • FrontTelescopic
  • RearSpring loaded hydraulic type (monoshock)

    Electricals

  • Battery12V 7Ah
  • Head lamp12V 35/35W
